“ESC Thermal Protection” to 105℃/221℉ (this refers to the internal temperature of the ESC).

Stop using the ESC when its casing temperature exceeds 90℃/194℉ otherwise, your ESC will get destroyed and may also get your motor damaged.

Hobbypower esc manual full#

Do not hold the vehicle in the air and rev it up to full throttle, as rubber tires can “expand” to an extreme size or even crack to cause serious injury.

Please use a soldering iron with the power of at least 60W to solder all input/output wires and connectors.

Hobbypower esc manual manuals#

Read through the manuals of all power devices and chassis and ensure the power configuration is rational before using this unit.Ensure all devices are well connected, in order to prevent poor connections that may cause your vehicle to lose control or other unpredictable issues like damage to the device.Ensure all wires and connections are well insulated before connecting the ESC to related devices, as the short circuit will damage your ESC.

Hobbypower esc manual upgrade#

HOBBYWING's new RTR upgrade ESC specially develops on the basis of constant research, technical analysis and performance comparisons, available via the authorized dealer.ĬEN GST-E upgrade, Traxxas XO-1, LOSI 5IVE UPGRADE Learn more. Firmware upgrade via HOBBYWING multifunction LCD program box (item sold separately).Advanced programming via portable LED program card or multifunction LCD program box.Single-button ESC programming and factory reset.Capacitor Protection(Only MAX5)：Innovative Capacitor Protection effectively protects capacitors from exploding and causing irreversible damage to the ESC because of overload.Multiple protections: motor lock-up protection, low-voltage cutoff protection, thermal protection, overload protection, and fail-safe (throttle signal loss protection).5 levels of acceleration /punch from soft to aggressive for different vehicles, tires and tracks.Proportional brake with 9 levels of brake amount/maximum brake force and 9 levels of drag brake force.Separate programming port to easily connect the LED program card or the LCD program box to the ESC.produced at the battery and ESC connecting moment.The built-in spark-proof circuit effectively protects not only battery and ESC connectors from damage but also users from physical injury (to hands) caused by strong electrical sparks.Highly reliable electronic switch avoids troubles which may happen to traditional mechanical switch due to dirt, water, dash and etc.peak current of 6A/25A for easily driving big torque servos and high voltage servos. Super internal switch-mode BEC with switchable voltage of 6V/7.4V and a cont.Fully waterproof design for all weather conditions.Compatible with sensorless brushless motors and sensored brushless motors (only in sensorless mode).(3) 10 AWG, 200C Black wires for a brushless motor.
